Why SolidWorks Flow Simulation is Key to Managing Thermal Issues in Equipment Operations?



        SolidWorks Flow Simulation is a powerful tool that can be used to quickly and easily assess the thermal performance of equipment. By using SolidWorks Flow Simulation, engineers can quickly identify potential areas of improvement in their designs and make necessary changes before manufacturing. Additionally, SolidWorks Flow Simulation can be used to evaluate the impact of different operating conditions on equipment performance.



        SolidWorks Flow Simulation provides reliable solution for managing thermal issues in equipment operations. Its comprehensive suite of tools enables users to simulate, analyze, and modify their designs with ease. Additionally, its user-friendly interface makes it easy to set up simulations quickly and accurately. With the help of SolidWorks Flow Simulation, engineers can effectively optimize their designs while ensuring that they meet the requirements of their projects’ thermal performance goals.

For more info, reach us at +91 94454 24704, mail to mktg@egs.co.in, visit us www.egsindia.com



THERMAL OPTIMIZATION OF HEAT SINK’S USING SOLIDWORKS FLOW SIMULATION

SolidWorks Flow Simulation helps Designers in Evaluating the performance of the fins of a solid body that is generating heat.

Using SolidWorks Flow Simulation, we can accurately capture the thin walls of the geometry by its advanced meshing algorithm. (Refer to Image 1- We can Enable minimum wall thickness of the model geometry)

Image 1: Automatic Mesh

Image 2: Thin Wall Optimization Mesh

SolidWorks Flow Simulation also provides the manual mesh type option for the users who require additional accuracy due to stringent design criteria.

Using manual mesh type, users can add the control planes (Refer to image 3) at the required locations.

Image 3: Manual Mesh

Image 4: After Applying Control Plane

Result:

Benefits:

ØIdentify the thermal hotspots of your products.

ØEngineers can easily improve the thermal efficiency of your products.

ØManufacturers of Electronic Components, IOT Devices, Instrument Clusters, Hi-tech Devices, etc. can be benefitted from this engineering tool.
